How to Cruise Ocean Threat Without Sinking Using TheHive 3.1 & Cortex 2.1

Paris, France. The Sun is shining on the city of lights and temperatures are quite high, even for the summer season. Life is good. As a matter of fact, life is excellent.

TheHive Master Cooks are about to go on vacation for a few weeks. But before they pack up their Patagonia bags and leave the sandy beaches for those who enjoy them, preferring mountains, trails, walking and breathing fresh air with family and friends, they would like to make a significant contribution to help TheHive and Cortex users fight cyberattacks even better than they already do. And maybe convince those who don’t that free, open source software is not a joke or a geek fad.

We’d like to welcome to the stage our latest babies, which we are really proud of: TheHive 3.1 and Cortex 2.1, the new versions of the power duo which make digital forensics, incident response and, to an extent, cyber threat intelligence, better, faster, happier, regular exercising (well you know the Radiohead song so we’ll let you continue singing along) since early 2017.

While our project might seem very young, it is not. We’ve been working steadily on TheHive, using it (i.e. eating our own dog food) since early 2014 before releasing it at the end of 2016 once we were satisfied with it, as a token of gratitude to a community that helped us due our jobs in various ways. We then extracted what has become Cortex from its core to ship it as a separate product in February 2017. And we kept improving them at a steady piece for the collective benefit of incident responders, forensicators and threat analysts. And adoption has been rather spectacular. Thanks to all of our users for their love and support!

We believe we are at a moment where people could not brush us off anymore as amateurs. Try TheHive and Cortex, preferably with MISP and get a taste of what professional, free and open source software can be.

TheHive 3.1 and Cortex 2.1 are feature-packed and we won’t be able to cover them all in detail in a single blog post. Rather, we’d like to concentrate on a few important ones.

Stable, Pre-release Channels and New Repositories

We’d like to point out that, in order to improve our release process and given the number of features that we added, TheHive 3.1 and Cortex 2.1 are release candidates at this stage. So we encourage you to test them and report back any bugs or issues you encounter so we can address them and make the final releases as rock-solid as possible.

We have now two release channels: a stable one that should be used for production systems and a pre-release channel that should be used to try the release candidates such as TheHive 3.1-RC1 and Cortex 2.1-RC1, the subjects of this blog post, and help us iron out bugs before adding them to the stable channel. Those who love living on the bleeding edge may be tempted by running the release candidates on their production environment given all the candy and icing we added. They are at liberty of doing so but we don’t want to hear anyone one whining about an RC that broke everything and asking for their money back grin.

We also moved our package and binary repositories to https://bintray.com/thehive-project and Docker images are now under thehiveproject.

Please check TheHive Installation and Cortex Installation guides for further details.

MISP with a Purpose

In previous releases of TheHive, whenever you configured a MISP instance, it was used to import events from and export cases to. Starting from TheHive 3.1.0, we added a purpose to the configuration file. By default, any added MISP instance will be used for import and export (ImportAndExport). However you can configure it to be used for importing events only (ImportOnly) or exporting cases only (ExportOnly).

Extended Events

When an analyst attempts to update a MISP event on which the account used by TheHive to connect to the MISP instance is not part of the original author’s organization, previous versions of TheHive will display a you do not have permission to do that error produced by MISP. Starting from TheHive 3.1, analysts have the ability to create a MISP extended event.

Task Grouping

Case tasks can now be associated with task groups. For example, you could create groups called Identification and Malware Analysis, Containment and Communication and add tasks to them. Of course, this new feature can be used when designing case templates as well.

Import Observables from Analyzer Output

If analyzers produce a set of artifacts in their output (which is the case of several existing ones), TheHive will give you the ability to select those artifacts very easily and add them to your case as observables.

ZIP File Upload

Austin Haigh contributed an important feature which will allow analysts to directly import password-protected ZIP files into a case. The code uses the supplied password when adding the archive to extract its contents and add them one by one to the existing set of observables. This is highly practical when you want to add suspicious files without risking an accidental click which would compromise your endpoint or having to unzip archives containing such files first then add them one by one to TheHive.

Revamped Search Page

The search page has been completely revamped as shown in the screenshot below:

The New Search Page

You can now select your search scope (cases, tasks, observables, alerts, analyser reports a.k.a. jobs or even the audit logs), apply filters and search TheHive without having to resort to complex, mind numbing Lucene syntax.

Responders and PAP

Last but not least, TheHive and Cortex offer you response capabilities (i.e. perform an action depending on the context) thanks to a new breed of programs called … wait for it … wait for it … responders. TADA!

Responders are very similar to analyzers. In fact we’ve taken the concept and extended it to apply to different elements in TheHive: alerts, cases, tasks, task logs, and observables of course.

Responders in Action

You can reuse almost the same principles that apply to analyzers to write your own responders and if you are feeling generous, contribute them to the community. To give you a head start, we published a sample Mailer responder which, when customized for your environment, should allow you to send emails to inform your fellow analysts that a case has been created and that their help is required. Another example could be the ability to respond to a suspicious email report from a user, which is displayed as an alert, that they can safely ignore the corresponding email.

Like an analyzer, a responder can have two or more service interaction files (or flavors) to allow it to perform different actions. For example, a Mailer responder can send messages using several body templates.

Thanks to our long-time friend Andras Iklody from MISP Project who brought that to our attention, responders (and analyzers starting from Cortex 2.1) support PAP, the Permissible Actions Protocol.

Running into Troubles?

Something does not work as expected? You have troubles installing or upgrading? Spotted new bugs? No worries, please open issues on GitHub or comment on existing ones, join our user forum, contact us on Gitter, or send us an email at support@thehive-project.org. We are here to help.







EmlParser: a New Cortex Analyzer for EML Files

The new EmlParser analyzer which we included in Cortex-Analyzers 1.12.0 leverages the eml_parser python library written by GOVCERT-LU. It parses EML email,  a MIME RFC 822 standard format, and extract all the information to help the analyst triage and investigate. EmlParser will prove very useful when analyzing observables imported from Synapse alerts.

You might notice that the analyzer’s requirements.txt installs the eml_parser library from one of our repositories. The original library dependencies contains file_magic library which brokes other analyzers that use python-magic. GOVCERT-LU is addressing this situation in their code but the installation process still considers file-magic as a mandatory library. We decided to consider it as an extra requirement.

Screen Shot 2018-07-26 at 08.19.11.png
Screen Shot 2018-07-26 at 08.19.31.png
EmlParser: short and long report samples

Get It While Supply Lasts!

To update your Cortex analyzers to 1.12.0, run the following commands:

cd path/to/Cortex-Analyzers

git pull

for I in analyzers/*/requirements.txt; do sudo -H pip2 install -r $I; done && \

for I in analyzers/*/requirements.txt; do sudo -H pip3 install -r $I || true; done

Once done, do not forget to login to Cortex as an orgadmin and click on the Refresh Analyzers button.

Update TheHive Report Templates

If you are using TheHive, get the latest version of  the report templates and import them into TheHive.

Running Into Trouble?

Shall you encounter any difficulty, please join our  user forum, contact us on Gitter, or send us an email at support@thehive-project.org. We will be more than happy to help!

Unveiling Synapse

When we’re not busy cooking new features, we go back to the trenches and face incidents like many of our fellow analysts who read our publications and use our tools. To do so, we swap our chef toques for firefighter helmets, not only because such shiny headwear is cool, but mainly because incident response (IR) is, at its very heart, firefighting (minus all the dangerous stuff).

If you think about it, when handling incidents you can see everything from cats in trees (spam) to major fire (APT). Thankfully, there are more cats to bring down than fire to extinguish. That being said, a big herd of cats could be a serious threat to your organization, to your mental health or both.

We tend to forget that incident handlers are humans, not robots. Unlike our metal cyberfriends, we need diversity. We can’t risk insanity like Charlie Chaplin in Modern Times if we can avoid it. Unfortunately IR can be highly repetitive, especially if you only have cats to deal with.

Some could say ‘Nah, this is minor, nothing critical here’ but at some point, an analyst brainwashed by the same tasks again and again will be led to fault. In the worst case scenario, one could see an alert and immediately categorize it as false positive without any further consideration. Because ‘this alert is always a false positive’, until the day it is not…

Automation, a Solution?

Intuitively, we look in the direction of automation in order to minimize what we call ‘zombie’ tasks: highly repetitive and brainless tasks that need to be done. We believe that doing so will allow incident handlers to focus on the analysis and not on the tedious side of IR. Ultimately, we hope it will keep analysts stimulated and in a state of alert. Also, it should reduce time and effort spent on the low-hanging fruits.

One of the most dreary tasks in our opinion is to record the context around an incident.
What is the problem? When did it happen? What’s the origin? Who are the victims? How many are there? Answers to these questions let you have an overview of what is happening and are valuable to correlate incidents. So it is worth taking some minutes to add this information to your case. Sadly, most of the time it will look like a succession of ‘Ctrl+C; Alt+Tab; Ctrl+V’ from your incident source to TheHive. Exactly the kind of tasks we want to forego.

Specifications

Having identified the threat that apathetic analysts pose, the root cause (highly repetitive tasks) and a solution (automate the recording of incident context), the question of the implementation has been raised.

The first challenge to solve is the number of incident sources. Almost everything can trigger an incident: a firewall, an IDS, antivirus, SIEM, users, etc… So the application must be designed to accept several sources and must permit to easily integrate new ones. And instead of having to configure multiple alert feeders to supply alerts to TheHive, we would have only one. To some extent, it can be assimilated to a meta feeder.

And if the application works as intended, we still have a second challenge. Let’s say you, dear reader, and ourselves use the galaxy renowned Stargazer IDS. Maybe you’d like to include the full packet capture in the case but we wouldn’t. Using the same product doesn’t mean using it the same way. So we have a variety of sources and for each source, we have a variety of configurations and workflows. Hence any app we design needs to accept multiple configurations and workflows for any given source.

Finally: the third challenge. We want to make the most out of TheHive. Creating cases, creating alerts, assigning cases, adding logs, adding observables … all those actions are not an option.

Synapse

After several trials and failures, we came up with Synapse. Basically it is a Python 3 app which sits between TheHive and your incident sources:

Screen Shot 2018-07-18 at 09.54.28.png
Synapse Overview

To solve the first and third challenge, we rely on connectors. A connector is a Python object dedicated to interact with a security device. In the picture above, you can see the Exchange Connector and TheHive Connector. To extend the number of sources, you just have to develop the connector that corresponds to your device.

Regarding the second challenge, we rely on workflows. Workflows are python scripts who use connectors to automate repetitive tasks when tracking a case. Not happy with the current workflow? Develop your own using the connectors.

At this point, you probably wonder why there’s an API in the picture above. Well, the API is the link between the user and the workflows. By hitting a specific endpoint of the Synapse’s API, the corresponding workflow will be launched. That way the user can choose what to launch, especially if they are only interested in a particular workflow. Moreover, using an API allows us to listen to TheHive’s real-time stream and initiate some actions like closing a QRadar offense when the related case is solved.

At the moment, Synapse includes the Exchange connector and the associated Ews2Case workflow. The workflow features:

  • Case creation from emails
  • Case assignment
  • Adding email bodies to task logs
  • Adding email replies to the case
  • Adding email attachments as observables

And of course, everything is done to minimize the number of clicks! Check the workflow documentation to understand how it works under the hood.

We’re still working on the QRadar connector and the associated workflows but if you can’t wait, have a look at the work done by the community like pierrebarlet’s script.

Check it Out

As usual, Synapse is an open source and free software released under the AGPL (Affero General Public License).

Synapse has its own repository. Start with the user guide and read about the workflow you want to use as you’ll need to configure it.

Troubles?

Shall you encounter any difficulty, please join our user forum, contact us on Gitter, or send us an email at support@thehive-project.org. We will be more than happy to help!

The Mind-Boggling Implications of Multi-Tenancy

TheHive offers a powerful yet generic query API for all the data stored by the platform in the underlying Elasticsearch database.

Thanks to its DSL (Domain Specific Language), TheHive can handle complex search queries such as the following:

Among all the unassigned tasks, show me all those associated with cases which severity is high but also contain the highest number of observables which datatype is  ‘mail’

When faced with such complex queries, TheHive translates them using its DSL and sends them over to Elasticsearch to obtain the results. TheHive’s dashboards draw their power from such querties.

And while such capability is highly desirable in our opinion, a capability that we will further leverage to add a completely revamped search module in the upcoming Cerana 1 (TheHive 3.1) release, it greatly complicates RBAC (or multi-tenancy) in TheHive.

Screen Shot 2018-06-27 at 11.50.39.png
A Sneak Peek at the New Search Module of the Upcoming Cerana 1 (TheHive 3.1) Release

Indeed, in the RBAC world, the conversion of any search queries submitted to TheHive into an Elasticsearch one is fully dependent on the user context. The user view must be kept within the boundaries of the group or groups to which they belong. Each search filter,  each search parameter, must return only the results that the user can view.

The data scope needs to be clearly identified at the case level. To perform a search against task logs for example, TheHive will need to identify the parent task log, then identify the parent case and only then verify the scope. This is no small undertaking.

Similarities across cases or alerts, such as the Related Cases feature or the relationships between a given alert and existing cases, would need additional work that has not been clearly identified at this stage. But the difficulties do not stop there. Any element that has no clear relationship with case entities will have to be singled out and specific code would need to be added to limit access according to the RBAC rules. This will be clearly the case for the audit trail. Also, what should TheHive display when an analyst group is working on a case that shares observables with another one belonging to a different group? Shall it allow a limited view without any details so that groups may request from a super administrator to authorize both groups to collaborate on the investigation, something that distributed CERTs or SOCs in a large corporation may desire? Or shall it keep the data completely isolated as MSSPs which serve multiple customers with a single instance will require? We know the answer: make it configurable. But take a step back and think of the implications at the code (and security) level.

Contrary to the feature we added to Cortex 2, which allow multiple organizations to use a single Cortex instance, multi-tenancy in TheHive is a much more complex feature to implement and which is expected to have a significant impact on the platform’s performance. It will also need extreme caution to avoid blind spots that attackers (and not so innocent tenants) may exploit to circumvent scope limitations and extend their view to data they are not supposed to access. That’s why we had to delay it to Cerana 2 (TheHive 3.2), currently planned for the end of October 2018.

If you are well versed in Elasticsearch and Scala and willing to help implement this feature, please contact us at support@thehive-project.org.



Cortex4py 2 is Out!

Cortex, a free, open source software allows security analysts and threat hunters to analyze and enrich observables (IP addresses, hashes, domains, …) collected in the course of an investigation or received from third parties, for example through MISP, the de facto standard for threat sharing.

On March 29, 2018, we released Cortex 2, a major improvement over the previous version which brought, among other cool features, authentication, caching, multi-tenancy (RBAC) and rate limiting. Instead of deploying several Cortex 1 instances behind reverse proxies which would implement authentification, administrators can deploy a single Cortex 2, create multiple organizations and serve the needs of various information security populations while enjoying extra features.

On May 31, 2018, we published a brand new API guide so that developers can take advantage of the powerful REST API of the product. Sadly, Cortex4py, the FOSS Python library we provide to interact with the API was not compatible with Cortex 2. Until today.

Thanks to the hard work of our dear Nabil Adouani, we are happy to announce the immediate availability of Cortex4py 2.0.0, a complete rewrite of the library in Python 3. Cortex4py 2.0.0 is fully compatible with Cortex 2. However, it doesn’t work with Cortex 1.

While TheHive, the highly popular free and open source Security Incident Response Platform (SIRP) we develop has native support for many Cortex 2 instances, Python developers can leverage Cortex4py to interact with Cortex 2, manage organizations, users, analyzer configurations and analyze observables at scale from alternative SIRPs, SIEMs or custom scripts thanks to the 83 analyzers Cortex 2 has as of June 18, 2018.

Screen Shot 2018-06-18 at 20.01.27.png
Cortex 2: there is more than one way to interact with it

Use It

To install Cortex4py, use PIP3:

$ sudo -H pip3 install cortex4py

If you are using Python on a Windows operating system, please forgo the sudo command.

Usage

Cortex4py 2 comes with a usage guide which includes many examples. For example, if you want to fetch the last 10 successful jobs that have been executed against domain names and display the result summaries of those 10 jobs you could write something like:

Screen Shot 2018-06-18 at 19.58.45.png
Sample Python3 code to retrieve Cortex analyzer results

Migrating from Cortex4py 1

If you have already written scripts using Cortex4py 1.x (for Cortex 1), we tried to keep the already available methods. However, we recommend you adapt your code to leverage the new Cortex4py 2 classes and methods as soon as feasible. Moreover, the existing scripts must be updated to support authentication if you intend to use them with Cortex 2. Please read the Cortex4py 2 usage guide for more information.

Support

Cortex 2.0.0 is brand new software. As such, it might contain bugs and limitations. If you find any or encounter problems, please ask on our user forum, contact us on Gitter, or send us an email at support@thehive-project.org. We are here to help.

Cortex-Analyzers 1.10.2

On June 6, 2018, we released Cortex-Analyzers 1.10, which contained 11 new analyzers, bringing the total to 83 programs. You read that correctly: 83 ways to assess and gain insight on observables collected during the course of an investigation or while performing threat intelligence thanks to Cortex, our free & open source analysis engine. One day after, we published version 1.10.1 which fixed the name of the Anomali STAXX reports for TheHive. Since then we uncovered a few additional issues which version 1.10.2 corrects:

  • #273 & #283: two encoding issues in the ThreatCrowd JSON definition file
  • #275: the GreyNoise mini-report for TheHive did not produce any information when no record was found
  • #278: the IBM X-Force analyzer forced the TLP in its configuration
  • #279: the VMRay should authorize self-signed certificates
  • #280: the name of the IBM X-Force Exchange report folder was incorrect preventing TheHive from displaying mini-reports or usefully laid out long ones

To install this hotfix release on your Cortex instance:

$ cd /path/to/Cortex-Analyzers
$ sudo git pull

Then log in to the Cortex Web UI as an orgAdmin and click on Refresh Analyzers:

click

If you are using TheHive, make sure to download the latest version of the report templates and import them into your instance.

Support

Something does not work as expected? No worries, please join our user forum, contact us on Gitter, or send us an email at support@thehive-project.org. We are here to help.

TheHive 3.0.10 Released

Rejoice DFIR fighters! Your favorite Security Incident Response Platform has just gotten better. TheHive 3.0.10 (codename Cerana 0.10) is just out of the oven. Thomas and Nabil, as the true code Chefs they are, have fixed a number of issues and added a few enhancements in this release. Read on, update and defend your constituency!

Fixes

  • #446: keep observable reports when performing a case merge operation
  • #592: fix the error message when an observable is created with invalid data
  • #583: cases can be merged by using their case ID
  • #584: correct error messages when performing invalid searches
  • #586: a regression was introduced that prevented analyzer names from being reflected in the modal view of mini-reports
  • #512: there were situations were mini-reports won’t display upon job success
  • #522: under certain circumstances, TheHive failed to synchronize MISP events correctly
  • #555: private dashboards must not be searchable
  • #557: fix an error when a merged case is deleted

Enhancements

  • #579: rotate application.log to keep it from becoming huge
  • #564: when submitting a job to Cortex, send the case ID as well
  • #563: poll the status of connectors (MISP, Cortex) every minute and update the UX display accordingly
  • #548: sort related cases by the amount of shared observables
  • #546: display start and end times for closed tasks

Support

Something does not work as expected? You have troubles installing or upgrading? You have spotted new bugs? No worries, please join our user forum, contact us on Gitter, or send us an email at support@thehive-project.org. We are here to help.
